Bosch Surface Mount Break Glass DS1101i



Quick Overview:

• Microprocessor-based sound analysis technology (SAT).
• Available from Cheap Alarm Parts.
• Automatic environmental test circuitry.
• Sound check.



The Blurb:

The DS1100i Detector Series uses microprocessor-based sound analysis technology (SAT) to listen for the specific frequencies associated with breaking glass. The DS1101i, DS1101i‑BEL, DS1101i‑CHI, and DS1101i‑FRA can be used to detect breakage of plate, tempered, laminated and wired glass types. A built-in environmental test feature alerts the installer to false alarm hazards in harsh environments. The round detectors mount on the ceiling or walls.



All images and text are copyright Cheap Alarm Parts.



Specifications:

Current:	23 mA at 12 VDC
Voltage:	6 VDC to 15 VDC
Temperature:	-29°C to +49°C (-20°F to +120°F) For UL Certificated installations, 0°C to +49°C (+32°F to +120°F)
(RFI) Immunity:	No alarm or setup on critical frequencies in the range from 26 MHz to 950 MHz at 50 V/m.
Dimensions:	2.1 cm x 8.6 cm (0.83 in. x 3.4 in.)
Material:	High‑impact ABS plastic enclosure
Alarm:	Form C reed relay rated 3.5 W, 125 mA at 28 VDC for resistive loads.
Tamper:	Normally-closed (NC) cover‑activated tamper switch with separate terminals. Contacts rated at 28 VDC, 125 mA maximum.
